SKF Products List

1.1 Single row deep groove ball bearings

Principal   dimensions Designations
Bearing
d D B open or capped both side capped on one side
mm –
3 10 4 623 – 3x10x4
10 4 623-2RS1 623-RS1 3x10x4
10 4 623-2Z 623-Z 3x10x4
4 9 2,5 618/4 – 4x9x2,5
9 3,5 628/4-2Z – 4x9x3,5
9 4 638/4-2Z – 4x9x4
11 4 619/4-2Z – 4x11x4
11 4 619/4 – 4x11x4
12 4 604 – 4x12x4
12 4 604-2Z 604-Z 4x12x4
13 5 624 – 4x13x5
13 5 624-2Z 624-Z 4x13x5
16 5 634 – 4x16x5
16 5 634-2RS1 634-RS1 4x16x5
16 5 634-2RZ 634-RZ 4x16x5
16 5 634-2Z 634-Z 4x16x5
5 11 3 618/5 – 5x11x3
11 4 628/5-2Z – 5x11x4
11 5 638/5-2Z – 5x11x5
13 4 619/5-2Z – 5x13x4
13 4 619/5 – 5x13x4
16 5 625 – 5x16x5
16 5 625-2Z 625-Z 5x16x5
19 6 635 – 5x19x6
19 6 635-2RS1 635-RS1 5x19x6
19 6 635-2RZ 635-RZ 5x19x6
19 6 635-2Z 635-Z 5x19x6
6 13 3,5 618/6 – 6x13x3,5
13 5 628/6-2Z – 6x13x5
15 5 619/6-2Z – 6x15x5
15 5 619/6 – 6x15x5
19 6 626 – 6x19x6
19 6 626-2RSH 626-RSH 6x19x6
19 6 626-2RSL 626-RSL 6x19x6
19 6 626-2Z 626-Z 6x19x6
7 14 3,5 618/7 – 7x14x3,5
14 5 628/7-2Z – 7x14x5
17 5 619/7-2Z – 7x17x5
17 5 619/7 – 7x17x5
19 6 607 – 7x19x6
19 6 607-2RSH 607-RSH 7x19x6
19 6 607-2RSL 607-RSL 7x19x6
19 6 607-2Z 607-Z 7x19x6
22 7 627 – 7x22x7
22 7 627-2RSH 627-RSH 7x22x7
22 7 627-2RSL 627-RSL 7x22x7
22 7 627-2Z 627-Z 7x22x7
8 16 4 618/8 – 8x16x4
16 5 628/8-2RS1 – 8x16x5
16 5 628/8-2Z – 8x16x5
16 6 638/8-2Z – 8x16x6
19 6 619/8-2RS1 – 8x19x6
19 6 619/8-2Z – 8x19x6
19 6 619/8 – 8x19x6
19 6 607/8-2Z 607/8-Z 8x19x6
22 7 608 – 8x22x7
22 7 608-2RSH ▶ 608-RSH 8x22x7
22 7 608-2RSL 608-RSL 8x22x7
22 7 608-2Z 608-Z 8x22x7
22 11 630/8-2RS1 – 8x22x11
24 8 628 – 8x24x8
24 8 628-2RS1 628-RS1 8x24x8
24 8 628-2RZ 628-RZ 8x24x8
24 8 628-2Z 628-Z 8x24x8
28 9 638-2RZ 638-RZ 8x28x9
9 17 4 618/9 – 9x17x4
17 5 628/9-2RS1 – 9x17x5
17 5 628/9-2Z 628/9-Z 9x17x5
20 6 619/9-2Z – 9x20x6
20 6 619/9 – 9x20x6
24 7 609 – 9x24x7
24 7 609-2RSH 609-RSH 9x24x7
24 7 609-2RSL 609-RSL 9x24x7
24 7 609-2Z 609-Z 9x24x7
26 8 629 – 9x26x8
26 8 629-2RSH 629-RSH 9x26x8
26 8 629-2RSL 629-RSL 9x26x8
26 8 629-2Z 629-Z 9x26x8
10 19 5 61800-2RS1 – 10x19x5
19 5 61800-2Z – 10x19x5
19 5 61800 – 10x19x5
22 6 61900-2RS1 – 10x22x6
22 6 61900-2Z – 10x22x6
22 6 61900 – 10x22x6
26 8 6000 – 10x26x8
26 8 6000-2RSH 6000-RSH 10x26x8
26 8 6000-2RSL 6000-RSL 10x26x8
26 8 6000-2Z ▶ 6000-Z 10x26x8
26 12 63000-2RS1 – 10x26x12
28 8 16100-2Z – 10x28x8
28 8 16100 – 10x28x8
30 9 6200 – 10x30x9
30 9 6200-2RSH 6200-RSH 10x30x9
30 9 6200-2RSL 6200-RSL 10x30x9
30 9 6200-2Z 6200-Z 10x30x9
30 14 62200-2RS1 – 10x30x14
35 11 6300 – 10x35x11
35 11 6300-2RSH 6300-RSH 10x35x11
35 11 6300-2RSL 6300-RSL 10x35x11
35 11 6300-2Z 6300-Z 10x35x11
35 17 62300-2RS1 – 10x35x17
12 21 5 61801-2RS1 – 12x21x5
21 5 61801-2Z – 12x21x5
21 5 61801 – 12x21x5
24 6 61901-2RS1 – 12x24x6
24 6 61901-2Z – 12x24x6
24 6 61901 – 12x24x6
28 8 6001 – 12x28x8
28 8 6001-2RSH 6001-RSH 12x28x8
28 8 6001-2RSL 6001-RSL 12x28x8
28 8 6001-2Z 6001-Z 12x28x8
28 12 63001-2RS1 – 12x28x12
30 8 16101-2RS1 – 12x30x8
30 8 16101-2Z – 12x30x8
30 8 16101 – 12x30x8
32 10 6201 – 12x32x10
32 10 6201-2RSH 6201-RSH 12x32x10
32 10 6201-2RSL 6201-RSL 12x32x10
32 10 6201-2Z 6201-Z 12x32x10
32 14 62201-2RS1 – 12x32x14
37 12 6301 – 12x37x12
37 12 6301-2RSH 6301-RSH 12x37x12
37 12 6301-2RSL 6301-RSL 12x37x12
37 12 6301-2Z 6301-Z 12x37x12
37 17 62301-2RS1 – 12x37x17
15 24 5 61802-2RS1 – 15x24x5
24 5 61802-2Z – 15x24x5
24 5 61802 – 15x24x5
28 7 61902-2RS1 – 15x28x7
28 7 61902-2RZ – 15x28x7
28 7 61902-2Z – 15x28x7
28 7 61902 – 15x28x7
32 8 16002 – 15x32x8
32 8 16002-2Z 16002-Z 15x32x8
32 9 6002 – 15x32x9
32 9 6002-2RSH 6002-RSH 15x32x9
32 9 6002-2RSL 6002-RSL 15x32x9
32 9 6002-2Z 6002-Z 15x32x9
32 13 63002-2RS1 – 15x32x13
35 11 6202 – 15x35x11
35 11 6202-2RSH 6202-RSH 15x35x11
35 11 6202-2RSL 6202-RSL 15x35x11
35 11 6202-2Z 6202-Z 15x35x11
35 14 62202-2RS1 – 15x35x14
42 13 6302 – 15x42x13
42 13 6302-2RSH 6302-RSH 15x42x13
42 13 6302-2RSL 6302-RSL 15x42x13
42 13 6302-2Z 6302-Z 15x42x13
42 17 62302-2RS1 – 15x42x17
52 7 61808-2RS1 – 15x52x7
17 26 5 61803-2RS1 – 17x26x5
26 5 61803-2RZ – 17x26x5
26 5 61803-2Z – 17x26x5
26 5 61803 – 17x26x5
30 7 61903-2RS1 – 17x30x7
30 7 61903-2Z – 17x30x7
30 7 61903-2RZ – 17x30x7
30 7 61903 – 17x30x7
35 8 16003-2Z – 17x35x8
35 8 16003 – 17x35x8
35 10 6003 – 17x35x10
35 10 6003-2RSH 6003-RSH 17x35x10
35 10 6003-2RSL 6003-RSL 17x35x10
35 10 6003-2Z 6003-Z 17x35x10
35 14 63003-2RS1 – 17x35x14
40 12 6203 – 17x40x12
40 12 6203-2RSH 6203-RSH 17x40x12
40 12 6203-2RSL 6203-RSL 17x40x12
40 12 6203-2Z 6203-Z 17x40x12
40 12 6203 ETN9 – 17x40x12
40 16 62203-2RS1 – 17x40x16
47 14 6303 – 17x47x14
47 14 6303-2RSH 6303-RSH 17x47x14
47 14 6303-2RSL 6303-RSL 17x47x14
47 14 6303-2Z 6303-Z 17x47x14
47 19 62303-2RS1 – 17x47x19
62 17 6403 – 17x62x17
20 32 7 61804-2RS1 – 20x32x7
32 7 61804-2RZ – 20x32x7
32 7 61804 – 20x32x7
37 9 61904-2RS1 – 20x37x9
37 9 61904-2RZ – 20x37x9
37 9 61904 – 20x37x9
42 8 16004 – 20x42x8
42 12 6004 – 20x42x12
42 12 6004-2RSH 6004-RSH 20x42x12
42 12 6004-2RSL 6004-RSL 20x42x12
42 12 6004-2Z 6004-Z 20x42x12
42 16 63004-2RS1 – 20x42x16
47 14 6204 – 20x47x14
47 14 6204-2RSH 6204-RSH 20x47x14
47 14 6204-2RSL 6204-RSL 20x47x14
47 14 6204-2Z 6204-Z 20x47x14
47 14 6204 ETN9 – 20x47x14
47 18 62204-2RS1 – 20x47x18
52 15 6304-2RSL 6304-RSL 20x52x15
52 15 6304 – 20x52x15
52 15 6304-2RSH 6304-RSH 20x52x15
52 15 6304-2Z 6304-Z 20x52x15
52 15 6304 ETN9 – 20x52x15
52 21 62304-2RS1 – 20x52x21
72 19 6404 – 20x72x19
22 50 14 62/22-2RS1 – 22x50x14
50 14 62/22 – 22x50x14
56 16 63/22 – 22x56x16
22xx
25 37 7 61805-2RS1 – 25x37x7
37 7 61805-2RZ – 25x37x7
37 7 61805 – 25x37x7
42 9 61905-2RS1 – 25x42x9
42 9 61905-2RZ – 25x42x9
42 9 61905 – 25x42x9
47 8 16005 – 25x47x8
47 12 6005 – 25x47x12
47 12 6005-2RSH 6005-RSH 25x47x12
47 12 6005-2RSL 6005-RSL 25x47x12
47 12 6005-2Z 6005-Z 25x47x12
47 16 63005-2RS1 – 25x47x16
52 15 6205 – 25x52x15
52 15 6205-2RSH 6205-RSH 25x52x15
52 15 6205-2RSL 6205-RSL 25x52x15
52 15 6205-2Z 6205-Z 25x52x15
52 15 6205 ETN9 – 25x52x15
52 18 62205-2RS1 – 25x52x18
62 17 6305 – 25x62x17
62 17 6305-2RSH 6305-RSH 25x62x17
62 17 6305-2RZ 6305-RZ 25x62x17
62 17 6305-2Z 6305-Z 25x62x17
62 17 6305 ETN9 – 25x62x17
62 24 62305-2RS1 – 25x62x24
80 21 6405 – 25x80x21
28 58 16 62/28 – 28x58x16
68 18 63/28 – 28x68x18
30 42 7 61806-2RS1 – 30x42x7
42 7 61806-2RZ – 30x42x7
42 7 61806 – 30x42x7
47 9 61906-2RS1 – 30x47x9
47 9 61906-2RZ – 30x47x9
47 9 61906 – 30x47x9
55 9 16006 – 30x55x9
55 13 6006 – 30x55x13
55 13 6006-2RS1 6006-RS1 30x55x13
55 13 6006-2RZ 6006-RZ 30x55x13
55 13 6006-2Z 6006-Z 30x55x13
55 19 63006-2RS1 – 30x55x19
62 16 6206 – 30x62x16
62 16 6206-2RSH 6206-RSH 30x62x16
62 16 6206-2RZ 6206-RZ 30x62x16
62 16 6206-2Z 6206-Z 30x62x16
62 16 6206 ETN9 – 30x62x16
62 20 62206-2RS1 – 30x62x20
72 19 6306 – 30x72x19
72 19 6306-2RSH 6306-RSH 30x72x19
72 19 6306-2RZ 6306-RZ 30x72x19
72 19 6306-2Z 6306-Z 30x72x19
72 19 6306 ETN9 – 30x72x19
72 27 62306-2RS1 – 30x72x27
90 23 6406 – 30x90x23
35 47 7 61807-2RS1 – 35x47x7
47 7 61807-2RZ – 35x47x7
47 7 61807 – 35x47x7
55 10 61907-2RS1 – 35x55x10
55 10 61907-2RZ – 35x55x10
55 10 61907 – 35x55x10
62 9 16007 – 35x62x9
62 14 6007 – 35x62x14
62 14 6007-2RS1 6007-RS1 35x62x14
62 14 6007-2RZ 6007-RZ 35x62x14
62 14 6007-2Z 6007-Z 35x62x14
62 20 63007-2RS1 – 35x62x20
72 17 6207 – 35x72x17
72 17 6207-2RSH 6207-RSH 35x72x17
72 17 6207-2Z 6207-Z 35x72x17
72 17 6207 ETN9 – 35x72x17
72 23 62207-2RS1 – 35x72x23
80 21 6307 – 35x80x21
80 21 6307 M – 35x80x21
80 21 6307-2RSH 6307-RSH 35x80x21
80 21 6307-2Z 6307-Z 35x80x21
80 31 62307-2RS1 – 35x80x31
100 25 6407 – 35x100x25
40 52 7 61808-2RZ – 40x52x7
52 7 61808 – 40x52x7
62 12 61908-2RS1 – 40x62x12
62 12 61908-2RZ – 40x62x12
62 12 61908 – 40x62x12
68 9 16008 – 40x68x9
68 15 6008 – 40x68x15
68 15 6008-2RS1 6008-RS1 40x68x15
68 15 6008-2RZ 6008-RZ 40x68x15
68 15 6008-2Z 6008-Z 40x68x15
68 21 63008-2RS1 – 40x68x21
80 18 6208 – 40x80x18
80 18 6208-2RSH 6208-RSH 40x80x18
80 18 6208-2RZ 6208-RZ 40x80x18
80 18 6208-2Z 6208-Z 40x80x18
80 18 6208 ETN9 – 40x80x18
80 23 62208-2RS1 – 40x80x23
90 23 6308 – 40x90x23
90 23 6308-2RSH 6308-RSH 40x90x23
90 23 6308-2RZ 6308-RZ 40x90x23
90 23 6308-2Z 6308-Z 40x90x23
90 33 62308-2RS1 – 40x90x33
110 27 6408 – 40x110x27
45 58 7 61809-2RS1 – 45x58x7
58 7 61809-2RZ – 45x58x7
58 7 61809 – 45x58x7
68 12 61909-2RS1 – 45x68x12
68 12 61909-2RZ – 45x68x12
68 12 61909 – 45x68x12
75 10 16009 – 45x75x10
75 16 6009 – 45x75x16
75 16 6009-2RS1 6009-RS1 45x75x16
75 16 6009-2Z 6009-Z 45x75x16
75 23 63009-2RS1 – 45x75x23
85 19 6209 – 45x85x19
85 19 6209-2RSH 6209-RSH 45x85x19
85 19 6209-2Z 6209-Z 45x85x19
85 23 62209-2RS1 – 45x85x23
100 25 6309 – 45x100x25
100 25 6309 M – 45x100x25
100 25 6309-2RSH 6309-RSH 45x100x25
100 25 6309-2Z 6309-Z 45x100x25
100 36 62309-2RS1 – 45x100x36
120 29 6409 – 45x120x29
50 65 7 61810-2RS1 – 50x65x7
65 7 61810-2RZ – 50x65x7
65 7 61810 – 50x65x7
72 12 61910-2RS1 – 50x72x12
72 12 61910-2RZ – 50x72x12
72 12 61910 – 50x72x12
80 10 16010 – 50x80x10
80 16 6010 – 50x80x16
80 16 6010-2RS1 6010-RS1 50x80x16
80 16 6010-2RZ 6010-RZ 50x80x16
80 16 6010-2Z 6010-Z 50x80x16
80 23 63010-2RS1 – 50x80x23
90 20 6210 – 50x90x20
90 20 6210 M – 50x90x20
90 20 6210-2RSH 6210-RSH 50x90x20
90 20 6210-2Z 6210-Z 50x90x20
90 20 6210-2RZ 6210-RZ 50x90x20
90 23 62210-2RS1 – 50x90x23
110 27 6310 M – 50x110x27
110 27 6310-2RSH 6310-RSH 50x110x27
110 27 6310 – 50x110x27
110 27 6310-2Z 6310-Z 50x110x27
110 40 62310-2RS1 – 50x110x40
130 31 6410 – 50x130x31
55 72 9 61811-2RS1 – 55x72x9
72 9 61811-2RZ – 55x72x9
72 9 61811 – 55x72x9
80 13 61911-2RS1 – 55x80x13
80 13 61911-2RZ – 55x80x13
80 13 61911 – 55x80x13
90 11 16011 – 55x90x11
90 18 6011 M – 55x90x18
90 18 6011 – 55x90x18
90 18 6011-2RS1 6011-RS1 55x90x18
90 18 6011-2Z 6011-Z 55x90x18
100 21 6211 – 55x100x21
100 21 6211 M – 55x100x21
100 21 6211-2RSH 6211-RSH 55x100x21
100 21 6211-2Z 6211-Z 55x100x21
100 25 62211-2RS1 – 55x100x25
120 29 6311 – 55x120x29
120 29 6311 M – 55x120x29
120 29 6311-2RSH 6311-RSH 55x120x29
120 29 6311-2Z 6311-Z 55x120x29
120 43 62311-2RS1 – 55x120x43
140 33 6411 – 55x140x33
60 78 10 61812-2RS1 – 60x78x10
78 10 61812-2RZ – 60x78x10
78 10 61812 – 60x78x10
85 13 61912-2RS1 – 60x85x13
85 13 61912 – 60x85x13
85 13 61912-2RZ – 60x85x13
95 11 16012 – 60x95x11
95 18 6012 – 60x95x18
95 18 6012-2RS1 6012-RS1 60x95x18
95 18 6012-2RZ 6012-RZ 60x95x18
95 18 6012-2Z 6012-Z 60x95x18
110 22 6212 – 60x110x22
110 22 6212 M – 60x110x22
110 22 6212-2RSH 6212-RSH 60x110x22
110 22 6212-2Z 6212-Z 60x110x22
110 28 62212-2RS1 – 60x110x28
130 31 6312 M – 60x130x31
130 31 6312-2RSH 6312-RSH 60x130x31
130 31 6312-2Z 6312-Z 60x130x31
130 31 6312 – 60x130x31
130 46 62312-2RS1 – 60x130x46
150 35 6412 – 60x150x35
65 85 10 61813-2RS1 – 65x85x10
85 10 61813-2RZ – 65x85x10
85 10 61813 – 65x85x10
90 13 61913-2RS1 – 65x90x13
90 13 61913-2RZ – 65x90x13
90 13 61913 – 65x90x13
100 11 16013 – 65x100x11
100 18 6013 – 65x100x18
100 18 6013 M – 65x100x18
100 18 6013-2RS1 6013-RS1 65x100x18
100 18 6013-2Z 6013-Z 65x100x18
120 23 6213 M – 65x120x23
120 23 6213 – 65x120x23
120 23 6213-2RS1 6213-RS1 65x120x23
120 23 6213-2Z 6213-Z 65x120x23
120 31 62213-2RS1 – 65x120x31
140 33 6313 M – 65x140x33
140 33 6313 – 65x140x33
140 33 6313-2RS1 6313-RS1 65x140x33
140 33 6313-2Z 6313-Z 65x140x33
140 48 62313-2RS1 – 65x140x48
160 37 6413 – 65x160x37
70 90 10 61814-2RS1 – 70x90x10
90 10 61814-2RZ – 70x90x10
90 10 61814 – 70x90x10
100 16 61914 – 70x100x16
100 16 61914-2RS1 – 70x100x16
100 16 61914-2RZ – 70x100x16
110 13 16014 – 70x110x13
110 20 6014 M – 70x110x20
110 20 6014 – 70x110x20
110 20 6014-2RS1 6014-RS1 70x110x20
110 20 6014-2Z 6014-Z 70x110x20
125 24 6214 M – 70x125x24
125 24 6214 – 70x125x24
125 24 6214-2RS1 6214-RS1 70x125x24
125 24 6214-2Z 6214-Z 70x125x24
125 31 62214-2RS1 – 70x125x31
150 35 6314 – 70x150x35
150 35 6314 M – 70x150x35
150 35 6314-2RS1 6314-RS1 70x150x35
150 35 6314-2Z 6314-Z 70x150x35
150 51 62314-2RS1 – 70x150x51
180 42 6414 – 70x180x42
75 95 10 61815-2RS1 – 75x95x10
95 10 61815-2RZ – 75x95x10
95 10 61815 – 75x95x10
105 16 61915 – 75x105x16
105 16 61915-2RS1 – 75x105x16
105 16 61915-2RZ – 75x105x16
115 13 16015 – 75x115x13
115 20 6015 M – 75x115x20
115 20 6015 – 75x115x20
115 20 6015-2RS1 6015-RS1 75x115x20
115 20 6015-2RZ 6015-RZ 75x115x20
115 20 6015-2Z 6015-Z 75x115x20
130 25 6215 M – 75x130x25
130 25 6215 – 75x130x25
130 25 6215-2RS1 6215-RS1 75x130x25
130 25 6215-2Z 6215-Z 75x130x25
160 37 6315 – 75x160x37
160 37 6315 M – 75x160x37
160 37 6315-2RS1 6315-RS1 75x160x37
160 37 6315-2Z 6315-Z 75x160x37
190 45 6415 – 75x190x45
80 100 10 61816-2RS1 – 80x100x10
100 10 61816 – 80x100x10
110 16 61916-2RS1 – 80x110x16
110 16 61916-2RZ – 80x110x16
110 16 61916 – 80x110x16
125 14 16016 – 80x125x14
125 22 6016 – 80x125x22
125 22 6016-2RS1 6016-RS1 80x125x22
125 22 6016-2Z 6016-Z 80x125x22
140 26 6216 – 80x140x26
140 26 6216 M – 80x140x26
140 26 6216-2RS1 6216-RS1 80x140x26
140 26 6216-2Z 6216-Z 80x140x26
170 39 6316 M – 80x170x39
170 39 6316 – 80x170x39
170 39 6316-2RS1 6316-RS1 80x170x39
170 39 6316-2Z 6316-Z 80x170x39
200 48 6416 – 80x200x48
85 110 13 61817-2RS1 – 85x110x13
110 13 61817-2RZ – 85x110x13
110 13 61817 – 85x110x13
120 18 61917 – 85x120x18
130 14 16017 – 85x130x14
130 22 6017 – 85x130x22
130 22 6017-2RS1 6017-RS1 85x130x22
130 22 6017-2Z 6017-Z 85x130x22
150 28 6217 M – 85x150x28
150 28 6217 – 85x150x28
150 28 6217-2RS1 6217-RS1 85x150x28
150 28 6217-2Z 6217-Z 85x150x28
180 41 6317 – 85x180x41
180 41 6317 M – 85x180x41
180 41 6317-2RS1 6317-RS1 85x180x41
180 41 6317-2Z 6317-Z 85x180x41
210 52 6417 – 85x210x52
90 115 13 61818-2RS1 – 90x115x13
115 13 61818-2RZ – 90x115x13
115 13 61818 – 90x115x13
125 18 61918 – 90x125x18
140 16 16018 – 90x140x16
140 24 6018 M – 90x140x24
140 24 6018 – 90x140x24
140 24 6018-2RS1 6018-RS1 90x140x24
140 24 6018-2Z 6018-Z 90x140x24
160 30 6218 – 90x160x30
160 30 6218 M – 90x160x30
160 30 6218-2RS1 6218-RS1 90x160x30
160 30 6218-2Z 6218-Z 90x160x30
190 43 6318 M – 90x190x43
190 43 6318 – 90x190x43
190 43 6318-2RS1 6318-RS1 90x190x43
190 43 6318-2Z 6318-Z 90x190x43
225 54 6418 – 90x225x54
95 120 13 61819-2RS1 – 95x120x13
120 13 61819 – 95x120x13
130 18 61919-2RS1 – 95x130x18
130 18 61919 – 95x130x18
145 16 16019 – 95x145x16
145 24 6019 – 95x145x24
145 24 6019-2RS1 – 95x145x24
145 24 6019-2Z 6019-Z 95x145x24
170 32 6219 – 95x170x32
170 32 6219 M – 95x170x32
170 32 6219-2RS1 6219-RS1 95x170x32
170 32 6219-2Z 6219-Z 95x170x32
200 45 6319 – 95x200x45
200 45 6319 M – 95x200x45
200 45 6319-2RS1 6319-RS1 95x200x45
200 45 6319-2Z 6319-Z 95x200x45
100 125 13 61820-2RS1 – 100x125x13
125 13 61820-2RZ – 100x125x13
125 13 61820 – 100x125x13
140 20 61920 – 100x140x20
150 16 16020 – 100x150x16
150 24 6020 M – 100x150x24
150 24 6020 – 100x150x24
150 24 6020-2RS1 6020-RS1 100x150x24
150 24 6020-2Z 6020-Z 100x150x24
180 34 6220 – 100x180x34
180 34 6220 M – 100x180x34
180 34 6220-2RS1 6220-RS1 100x180x34
180 34 6220-2Z 6220-Z 100x180x34
215 47 6320 – 100x215x47
215 47 6320 M – 100x215x47
215 47 6320-2RS1 6320-RS1 100x215x47
215 47 6320-2Z 6320-Z 100x215x47
105 130 13 61821-2RS1 – 105x130x13
130 13 61821-2RZ – 105x130x13
130 13 61821 – 105x130x13
145 20 61921 – 105x145x20
160 18 16021 – 105x160x18
160 26 6021 – 105x160x26
160 26 6021 M – 105x160x26
160 26 6021-2RS1 6021-RS1 105x160x26
160 26 6021-2Z 6021-Z 105x160x26
190 36 6221 – 105x190x36
190 36 6221-2Z 6221-Z 105x190x36
225 49 6321-2Z 6321-Z 105x225x49
225 49 6321 – 105x225x49
110 140 16 61822-2RS1 – 110x140x16
140 16 61822-2RZ – 110x140x16
140 16 61822 – 110x140x16
150 20 61922 – 110x150x20
150 20 61922 MA – 110x150x20
170 19 16022 – 110x170x19
170 28 6022 – 110x170x28
170 28 6022 M – 110x170x28
170 28 6022-2RS1 6022-RS1 110x170x28
170 28 6022-2Z 6022-Z 110x170x28
200 38 6222 – 110x200x38
200 38 6222-2RS1 6222-RS1 110x200x38
200 38 6222-2Z 6222-Z 110x200x38
240 50 6322 – 110x240x50
240 50 6322 M – 110x240x50
120 150 16 61824-2RS1 – 120x150x16
150 16 61824-2RZ – 120x150x16
150 16 61824 – 120x150x16
165 22 61924 – 120x165x22
165 22 61924 MA – 120x165x22
180 19 16024 – 120x180x19
180 28 6024 MA – 120x180x28
180 28 6024 – 120x180x28
180 28 6024-2RS1 6024-RS1 120x180x28
180 28 6024-2Z 6024-Z 120x180x28
215 40 6224 – 120x215x40
215 40 6224 M – 120x215x40
215 40 6224-2RS1 6224-RS1 120x215x40
215 40 6224-2Z 6224-Z 120x215x40
260 55 6324 – 120x260x55
260 55 6324 M – 120x260x55
260 55 6324-2RS1 6324-RS1 120x260x55
260 55 6324-2Z 6324-Z 120x260x55
130 165 18 61826-2RS1 – 130x165x18
165 18 61826-2RZ – 130x165x18
165 18 61826 – 130x165x18
180 24 61926 – 130x180x24
200 22 16026 – 130x200x22
200 33 6026 M – 130x200x33
200 33 6026 – 130x200x33
200 33 6026-2RS1 6026-RS1 130x200x33
200 33 6026-2Z 6026-Z 130x200x33
230 40 6226 M – 130x230x40
230 40 6226 – 130x230x40
230 40 6226-2RS1 6226-RS1 130x230x40
230 40 6226-2Z 6226-Z 130x230x40
280 58 6326 – 130x280x58
280 58 6326 M – 130x280x58
140 175 18 61828-2RS1 – 140x175x18
175 18 61828-2RZ – 140x175x18
175 18 61828 – 140x175x18
190 24 61928 – 140x190x24
190 24 61928 MA – 140x190x24
210 22 16028 – 140x210x22
210 33 6028 M – 140x210x33
210 33 6028 – 140x210x33
210 33 6028-2RS1 6028-RS1 140x210x33
210 33 6028-2Z 6028-Z 140x210x33
250 42 6228 – 140x250x42
250 42 6228 MA – 140x250x42
300 62 6328 – 140x300x62
300 62 6328 M – 140x300x62
150 190 20 61830 – 150x190x20
190 20 61830 MA – 150x190x20
210 28 61930 MA – 150x210x28
225 24 16030 – 150x225x24
225 35 6030 M – 150x225x35
225 35 6030 – 150x225x35
225 35 6030-2RS1 6030-RS1 150x225x35
225 35 6030-2Z 6030-Z 150x225x35
270 45 6230 – 150x270x45
270 45 6230 M – 150x270x45
320 65 6330 – 150x320x65
320 65 6330 M – 150x320x65
160 200 20 61832 – 160x200x20
220 28 61932 – 160x220x28
220 28 61932 MA – 160x220x28
240 25 16032 – 160x240x25
240 38 6032 M – 160x240x38
240 38 6032 – 160x240x38
240 38 6032-2RS1 6032-RS1 160x240x38
240 38 6032-2Z 6032-Z 160x240x38
290 48 6232 – 160x290x48
290 48 6232 M – 160x290x48
340 68 6332 – 160x340x68
340 68 6332 M – 160x340x68
170 215 22 61834 – 170x215x22
230 28 61934 MA – 170x230x28
260 28 16034 – 170x260x28
260 42 6034 – 170x260x42
260 42 6034 M – 170x260x42
310 52 6234 – 170x310x52
310 52 6234 M – 170x310x52
360 72 6334 – 170x360x72
360 72 6334 M – 170x360x72
180 225 22 61836 – 180x225x22
250 33 61936 – 180x250x33
250 33 61936 MA – 180x250x33
280 31 16036 – 180x280x31
280 46 6036 – 180x280x46
280 46 6036 M – 180x280x46
320 52 6236 – 180x320x52
320 52 6236 M – 180x320x52
380 75 6336 – 180x380x75
380 75 6336 M – 180x380x75
190 240 24 61838 – 190x240x24
260 33 61938 – 190x260x33
260 33 61938 MA – 190x260x33
290 31 16038 – 190x290x31
290 46 6038 – 190x290x46
290 46 6038 M – 190x290x46
340 55 6238 – 190x340x55
340 55 6238 M – 190x340x55
400 78 6338 – 190x400x78
400 78 6338 M – 190x400x78
200 250 24 61840 – 200x250x24
280 38 61940 – 200x280x38
280 38 61940 MA – 200x280x38
310 34 16040 – 200x310x34
310 51 6040 – 200x310x51
310 51 6040 M – 200x310x51
360 58 6240 – 200x360x58
360 58 6240 M – 200x360x58
220 270 24 61844 – 220x270x24
300 38 61944 – 220x300x38
300 38 61944 MA – 220x300x38
340 37 16044 – 220x340x37
340 56 6044 – 220x340x56
340 56 6044 M – 220x340x56
400 65 6244 – 220x400x65
400 65 6244 M – 220x400x65
460 88 6344 M – 220x460x88
240 300 28 61848 – 240x300x28
320 38 61948 – 240x320x38
320 38 61948 MA – 240x320x38
360 37 16048 – 240x360x37
360 37 16048 MA – 240x360x37
360 56 6048 – 240x360x56
360 56 6048 M – 240x360x56
440 72 6248 M – 240x440x72
500 95 6348 M – 240x500x95
260 320 28 61852 – 260x320x28
360 46 61952 – 260x360x46
360 46 61952 MA – 260x360x46
400 44 16052 – 260x400x44
400 44 16052 MA – 260x400x44
400 65 6052 – 260x400x65
400 65 6052 M – 260x400x65
480 80 6252 M – 260x480x80
280 350 33 61856 – 280x350x33
350 33 61856 MA – 280x350x33
380 46 61956 – 280x380x46
380 46 61956 MA – 280x380x46
420 44 16056 – 280x420x44
420 44 16056 MA – 280x420x44
420 65 6056 – 280x420x65
420 65 6056 M – 280x420x65
500 80 6256 M – 280x500x80
300 380 38 61860 – 300x380x38
380 38 61860 MA – 300x380x38
420 56 61960 – 300x420x56
420 56 61960 MA – 300x420x56
460 50 16060 MA – 300x460x50
460 74 6060 M – 300x460x74
540 85 6260 M – 300x540x85
320 400 38 61864 – 320x400x38
400 38 61864 MA – 320x400x38
440 56 61964 MA – 320x440x56
480 50 16064 MA – 320x480x50
480 74 6064 M – 320x480x74
340 420 38 61868 – 340x420x38
420 38 61868 MA – 340x420x38
460 56 61968 MA – 340x460x56
520 57 16068 MA – 340x520x57
520 82 6068 M – 340x520x82
360 440 38 61872 MA – 360x440x38
480 56 61972 MA – 360x480x56
540 57 16072 MA – 360x540x57
540 82 6072 M – 360x540x82
380 480 46 61876 MA – 380x480x46
520 65 61976 MA – 380x520x65
560 57 16076 MA – 380x560x57
560 82 6076 M – 380x560x82
400 500 46 61880 MA – 400x500x46
540 65 61980 MA – 400x540x65
600 90 6080 M – 400x600x90
420 520 46 61884 MA – 420x520x46
560 65 61984 MA – 420x560x65
620 90 6084 M – 420x620x90
440 540 46 61888 MA – 440x540x46
600 74 61988 MA – 440x600x74
650 94 6088 M – 440x650x94
460 580 56 61892 MA – 460x580x56
620 74 61992 MA – 460x620x74
680 100 6092 MB – 460x680x100
480 600 56 61896 MA – 480x600x56
650 78 61996 MA – 480x650x78
700 100 6096 MB – 480x700x100
500 620 56 618/500 MA – 500x620x56
670 78 619/500 MA – 500x670x78
720 100 60/500 N1MAS – 500x720x100
530 650 56 618/530 MA – 530x650x56
710 82 619/530 MA – 530x710x82
780 112 60/530 N1MAS – 530x780x112
560 680 56 618/560 MA – 560x680x56
750 85 619/560 MA – 560x750x85
820 115 60/560 N1MAS – 560x820x115
600 730 60 618/600 MA – 600x730x60
800 90 619/600 MA – 600x800x90
870 118 60/600 MA – 600x870x118
630 780 69 618/630 MA – 630x780x69
850 100 619/630 N1MA – 630x850x100
920 128 60/630 N1MBS – 630x920x128
670 820 69 618/670 MA – 670x820x69
900 103 619/670 MA – 670x900x103
980 136 60/670 N1MAS – 670x980x136
710 870 74 618/710 MA – 710x870x74
950 106 619/710 MA – 710x950x106
1 030 140 60/710 MA – 710x1030x140
750 920 78 618/750 MA – 750x920x78
1 000 112 619/750 MA – 750x1000x112
1 090 150 60/750 MA – 750x1090x150
800 980 82 618/800 MA – 800x980x82
1 060 115 619/800 MA – 800x1060x115
1 150 155 60/800 N1MAS – 800x1150x155
850 1 030 82 618/850 MA – 850x1030x82
1 120 118 619/850 MA – 850x1120x118
900 1 090 85 618/900 MA – 900x1090x85
950 1 150 90 618/950 MA – 950x1150x90
1 000 1 220 100 618/1000 MA – 1000x1220x100
1 060 1 280 100 618/1060 MA – 1060x1280x100
1 120 1 360 106 618/1120 MA – 1120x1360x106
1 180 1 420 106 618/1180 MB – 1180x1420x106
1 320 1 600 122 618/1320 MA – 1320x1600x122
1 500 1 820 140 618/1500 TN – 1500x1820x140

1.2 ICOS oil sealed bearing units

Principal dimensions Designation
d D B
12 32 10 ICOS-D1B01 TN9
15 35 11 ICOS-D1B02 TN9
17 40 12 ICOS-D1B03 TN9
20 47 14 ICOS-D1B04 TN9
25 52 15 ICOS-D1B05 TN9
30 62 16 ICOS-D1B06 TN9

1.3 Single row deep groove ball bearings with a snap ring groove

Principal dimensions Designations
Bearings1) Snap ring
d D B
10 30 9 6200-ZNR 6200-2ZNR SP 30 10x30x9
30 9 6200 N 6200 NR SP 30 10x30x9
12 32 10 6201-ZNR 6201-2ZNR SP 32 12x32x10
32 10 6201 N 6201 NR SP 32 12x32x10
15 35 11 6202-ZNR 6202-2ZNR SP 35 15x35x11
35 11 6202 N 6202 NR SP 35 15x35x11
17 40 12 6203-ZNR 6203-2ZNR SP 40 17x40x12
40 12 6203 N 6203 NR SP 40 17x40x12
47 14 6303-ZNR 6303-2ZNR SP 47 17x47x14
47 14 6303 N 6303 NR SP 47 17x47x14
20 42 12 6004-ZNR 6004-2ZNR SP 42 20x42x12
42 12 6004 N 6004 NR SP 42 20x42x12
47 14 6204-ZNR 6204-2ZNR SP 47 20x47x14
47 14 6204 N 6204 NR SP 47 20x47x14
52 15 6304-ZNR 6304-2ZNR SP 52 20x52x15
52 15 6304 N 6304 NR SP 52 20x52x15
25 47 12 6005-ZNR 6005-2ZNR SP 47 25x47x12
47 12 6005 N 6005 NR SP 47 25x47x12
52 15 6205-ZNR 6205-2ZNR SP 52 25x52x15
52 15 6205 N 6205 NR SP 52 25x52x15
62 17 6305-ZNR 6305-2ZNR SP 62 25x62x17
62 17 6305 N 6305 NR SP 62 25x62x17
30 55 13 6006 N 6006 NR SP 55 30x55x13
62 16 6206-ZNR 6206-2ZNR SP 62 30x62x16
62 16 6206 N 6206 NR SP 62 30x62x16
72 19 6306-ZNR 6306-2ZNR SP 72 30x72x19
72 19 6306 N 6306 NR SP 72 30x72x19
35 62 14 6007 N 6007 NR SP 62 35x62x14
72 17 6207-ZNR 6207-2ZNR SP 72 35x72x17
72 17 6207 N 6207 NR SP 72 35x72x17
80 21 6307-ZNR 6307-2ZNR SP 80 35x80x21
80 21 6307 N 6307 NR SP 80 35x80x21
100 25 6407 N 6407 NR SP 100 35x100x25
40 68 15 6008 N 6008 NR SP 68 40x68x15
80 18 6208-ZNR 6208-2ZNR SP 80 40x80x18
80 18 6208 N 6208 NR SP 80 40x80x18
90 23 6308-ZNR 6308-2ZNR SP 90 40x90x23
90 23 6308 N 6308 NR SP 90 40x90x23
110 27 6408 N 6408 NR SP 110 40x110x27
45 75 16 6009 N 6009 NR SP 75 45x75x16
85 19 6209-ZNR 6209-2ZNR SP 85 45x85x19
85 19 6209 N 6209 NR SP 85 45x85x19
100 25 6309-ZNR 6309-2ZNR SP 100 45x100x25
100 25 6309 N 6309 NR SP 100 45x100x25
120 29 6409 N 6409 NR SP 120 45x120x29
50 80 16 6010 N 6010 NR SP 80 50x80x16
90 20 6210-ZNR 6210-2ZNR SP 90 50x90x20
90 20 6210 N 6210 NR SP 90 50x90x20
110 27 6310-ZNR 6310-2ZNR SP 110 50x110x27
110 27 6310 N 6310 NR SP 110 50x110x27
130 31 6410 N 6410 NR SP 130 50x130x31
55 90 18 6011 N 6011 NR SP 90 55x90x18
100 21 6211-ZNR 6211-2ZNR SP 100 55x100x21
100 21 6211 N 6211 NR SP 100 55x100x21
120 29 6311-ZNR 6311-2ZNR SP 120 55x120x29
120 29 6311 N 6311 NR SP 120 55x120x29
140 33 6411 N 6411 NR SP 140 55x140x33
60 95 18 6012 N 6012 NR SP 95 60x95x18
110 22 6212-ZNR 6212-2ZNR SP 110 60x110x22
110 22 6212 N 6212 NR SP 110 60x110x22
130 31 6312-ZNR 6312-2ZNR SP 130 60x130x31
130 31 6312 N 6312 NR SP 130 60x130x31
150 35 6412 N 6412 NR SP 150 60x150x35
65 100 18 6013 N 6013 NR SP 100 65x100x18
120 23 6213-ZNR 6213-2ZNR SP 120 65x120x23
120 23 6213 N 6213 NR SP 120 65x120x23
140 33 6313-ZNR 6313-2ZNR SP 140 65x140x33
140 33 6313 N 6313 NR SP 140 65x140x33
160 37 6413 N 6413 NR SP 160 65x160x37
70 110 20 6014 N 6014 NR SP 110 70x110x20
125 24 6214-ZNR 6214-2ZNR SP 125 70x125x24
125 24 6214 N 6214 NR SP 125 70x125x24
150 35 6314-ZNR 6314-2ZNR SP 150 70x150x35
150 35 6314 N 6314 NR SP 150 70x150x35
75 115 20 6015 N 6015 NR SP 115 75x115x20
130 25 6215 N 6215 NR SP 130 75x130x25
160 37 6315 N 6315 NR SP 160 75x160x37
80 125 22 6016 N 6016 NR SP 125 80x125x22
140 26 6216 N 6216 NR SP 140 80x140x26
85 130 22 6017 N 6017 NR SP 130 85x130x22
150 28 6217 N 6217 NR SP 150 85x150x28
90 140 24 6018 N 6018 NR SP 140 90x140x24
160 30 6218 N 6218 NR SP 160 90x160x30
95 170 32 6219 N 6219 NR SP 170 95x170x32
100 150 24 6020 N 6020 NR SP 150 100x150x24
100 180 34 6220 N 6220 NR SP 180 100x180x34
105 160 26 6021 N 6021 NR SP 160 105x160x26
110 170 28 6022 N 6022 NR SP 170 110x170x28
120 180 28 6024 N 6024 NR SP 180 120x180x28

1.4 Stainless steel deep groove ball bearings

Principal dimensions Designation
d D B
1 3 1 W 618/1 1x3x1
1,5 4 1,2 W 618/1.5 1,5x4x1,2
4 2 W 638/1.5-2Z 1,5x4x2
2 5 1,5 W 618/2 2x5x1,5
5 2,3 W 638/2-2Z 2x5x2,3
6 3 W 639/2-2Z 2x6x3
2,5 6 2,6 W 638/2.5-2Z 2,5x6x2,6
3 6 3 W 637/3-2Z 3x6x3
7 2 W 618/3 3x7x2
7 3 W 638/3-2Z 3x7x3
8 3 W 619/3-2Z 3x8x3
8 4 W 639/3-2Z 3x8x4
10 4 W 623-2RS1 3x10x4
10 4 W 623-2Z 3x10x4
4 7 2,5 W 627/4-2Z 4x7x2,5
9 2,5 W 618/4 4x9x2,5
9 4 W 638/4-2Z 4x9x4
11 4 W 619/4-2Z 4x11x4
12 4 W 604-2RS1 4x12x4
12 4 W 604-2Z 4x12x4
12 4 W 604 4x12x4
13 5 W 624-2RS1 4x13x5
13 5 W 624-2Z 4x13x5
16 5 W 634-2RS1 4x16x5
16 5 W 634-2Z 4x16x5
5 8 2,5 W 627/5-2Z 5x8x2,5
11 3 W 618/5 5x11x3
11 4 W 628/5-2Z 5x11x4
11 5 W 638/5-2Z 5x11x5
13 4 W 619/5-2RS1 5x13x4
13 4 W 619/5-2Z 5x13x4
13 4 W 619/5 5x13x4
14 5 W 605-2RS1 5x14x5
14 5 W 605-2Z 5x14x5
16 5 W 625-2RS1 5x16x5
16 5 W 625-2Z 5x16x5
16 5 W 625 5x16x5
6 10 3 W 627/6-2Z 6x10x3
13 3,5 W 618/6 6x13x3,5
13 5 W 628/6-2RS1 6x13x5
13 5 W 628/6-2Z 6x13x5
15 5 W 619/6-2Z 6x15x5
15 5 W 619/6 6x15x5
17 6 W 606-2RS1 6x17x6
17 6 W 606-2Z 6x17x6
19 6 W 626-2RS1 6x19x6
19 6 W 626-2Z 6x19x6
19 6 W 626 6x19x6
7 11 3 W 627/7-2ZS 7x11x3
14 3,5 W 618/7 7x14x3,5
14 5 W 628/7-2Z 7x14x5
17 5 W 619/7-2Z 7x17x5
17 5 W 619/7 7x17x5
19 6 W 607-2RS1 7x19x6
19 6 W 607-2Z 7x19x6
19 6 W 607 7x19x6
22 7 W 627-2RS1 7x22x7
22 7 W 627-2Z 7x22x7
22 7 W 627 7x22x7
8 12 3,5 W 637/8-2Z 8x12x3,5
16 4 W 618/8 8x16x4
16 5 W 628/8-2RS1 8x16x5
16 5 W 628/8-2Z 8x16x5
16 6 W 638/8-2Z 8x16x6
19 6 W 619/8-2RS1 8x19x6
19 6 W 619/8-2Z 8x19x6
19 6 W 619/8 8x19x6
22 7 W 608-2RS1 8x22x7
22 7 W 608-2Z 8x22x7
22 7 W 608 8x22x7
24 8 W 628-2Z 8x24x8
9 17 4 W 618/9 9x17x4
17 5 W 628/9-2RS1 9x17x5
17 5 W 628/9-2Z 9x17x5
20 6 W 619/9-2Z 9x20x6
20 6 W 619/9 9x20x6
24 7 W 609-2RS1 9x24x7
24 7 W 609-2Z 9x24x7
24 7 W 609 9x24x7
26 8 W 629-2RS1 9x26x8
26 8 W 629-2Z 9x26x8
10 19 5 W 61800-2RS1 10x19x5
19 5 W 61800-2Z 10x19x5
19 5 W 61800 10x19x5
19 7 W 63800-2Z 10x19x7
22 6 W 61900-2RS1 10x22x6
22 6 W 61900-2Z 10x22x6
22 6 W 61900 10x22x6
26 8 W 6000-2RS1 10x26x8
26 8 W 6000-2Z 10x26x8
26 8 W 6000 10x26x8
30 9 W 6200-2RS1 10x30x9
30 9 W 6200-2Z 10x30x9
30 9 W 6200 10x30x9
35 11 W 6300-2RS1 10x35x11
35 11 W 6300-2Z 10x35x11
35 11 W 6300 10x35x11
12 21 5 W 61801-2RS1 12x21x5
21 5 W 61801-2Z 12x21x5
24 6 W 61901-2RS1 12x24x6
24 6 W 61901-2Z 12x24x6
24 6 W 61901 12x24x6
28 8 W 6001-2RS1 12x28x8
28 8 W 6001-2Z 12x28x8
28 8 W 6001 12x28x8
32 10 W 6201-2RS1 12x32x10
32 10 W 6201-2Z 12x32x10
32 10 W 6201 12x32x10
37 12 W 6301-2RS1 12x37x12
37 12 W 6301-2Z 12x37x12
37 12 W 6301 12x37x12
15 24 5 W 61802-2RS1 15x24x5
24 5 W 61802-2Z 15x24x5
28 7 W 61902-2RS1 15x28x7
28 7 W 61902-2Z 15x28x7
28 7 W 61902 15x28x7
32 9 W 6002-2RS1 15x32x9
32 9 W 6002-2Z 15x32x9
32 9 W 6002 15x32x9
35 11 W 6202-2RS1 15x35x11
35 11 W 6202-2Z 15x35x11
35 11 W 6202 15x35x11
42 13 W 6302-2RS1 15x42x13
42 13 W 6302-2Z 15x42x13
42 13 W 6302 15x42x13
17 26 5 W 61803-2RS1 17x26x5
26 5 W 61803-2Z 17x26x5
30 7 W 61903-2RS1 17x30x7
30 7 W 61903-2Z 17x30x7
30 7 W 61903 17x30x7
35 10 W 6003-2RS1 17x35x10
35 10 W 6003-2Z 17x35x10
35 10 W 6003 17x35x10
40 12 W 6203-2RS1 17x40x12
40 12 W 6203-2Z 17x40x12
40 12 W 6203 17x40x12
47 14 W 6303-2RS1 17x47x14
47 14 W 6303-2Z 17x47x14
47 14 W 6303 17x47x14
20 32 7 W 61804-2RS1 20x32x7
32 7 W 61804-2Z 20x32x7
37 9 W 61904-2RS1 20x37x9
37 9 W 61904 20x37x9
42 12 W 6004-2RS1 20x42x12
42 12 W 6004-2Z 20x42x12
42 12 W 6004 20x42x12
47 14 W 6204-2RS1 20x47x14
47 14 W 6204-2Z 20x47x14
47 14 W 6204 20x47x14
52 15 W 6304-2RS1 20x52x15
52 15 W 6304-2Z 20x52x15
52 15 W 6304 20x52x15
25 37 7 W 61805-2RS1 25x37x7
37 7 W 61805-2Z 25x37x7
42 9 W 61905-2RS1 25x42x9
47 12 W 6005-2RS1 25x47x12
47 12 W 6005-2Z 25x47x12
47 12 W 6005 25x47x12
52 15 W 6205-2RS1 25x52x15
52 15 W 6205-2Z 25x52x15
52 15 W 6205 25x52x15
62 17 W 6305-2RS1 25x62x17
62 17 W 6305-2Z 25x62x17
62 17 W 6305 25x62x17
30 42 7 W 61806-2RS1 30x42x7
47 9 W 61906-2RS1 30x47x9
47 9 W 61906 30x47x9
55 13 W 6006-2RS1 30x55x13
55 13 W 6006-2Z 30x55x13
55 13 W 6006 30x55x13
62 16 W 6206-2RS1 30x62x16
62 16 W 6206-2Z 30x62x16
62 16 W 6206 30x62x16
72 19 W 6306-2RS1 30x72x19
72 19 W 6306-2Z 30x72x19
72 19 W 6306 30x72x19
35 47 7 W 61807-2RS1 35x47x7
55 10 W 61907-2RS1 35x55x10
62 14 W 6007-2RS1 35x62x14
62 14 W 6007-2Z 35x62x14
62 14 W 6007 35x62x14
72 17 W 6207-2RS1 35x72x17
72 17 W 6207-2Z 35x72x17
72 17 W 6207 35x72x17
80 21 W 6307-2RS1 35x80x21
40 62 12 W 61908-2RS1 40x62x12
68 15 W 6008-2RS1 40x68x15
68 15 W 6008-2Z 40x68x15
68 15 W 6008 40x68x15
80 18 W 6208-2RS1 40x80x18
80 18 W 6208-2Z 40x80x18
80 18 W 6208 40x80x18
45 68 12 W 61909-2RS1 45x68x12
75 16 W 6009-2RS1 45x75x16
75 16 W 6009-2Z 45x75x16
85 19 W 6209-2RS1 45x85x19
85 19 W 6209-2Z 45x85x19
50 65 7 W 61810-2RS1 50x65x7
80 16 W 6010-2RS1 50x80x16
80 16 W 6010-2Z 50x80x16
90 20 W 6210-2RS1 50x90x20
90 20 W 6210-2Z 50x90x20

1.5 Single row deep groove ball bearings with illing slots

Principal dimensions Designations
d D B With a snap ring Without a snap ring
25 62 17 305 305 NR SP 62 25x62x17
62 17 305-Z 305-ZNR SP 62 25x62x17
62 17 305-2Z 305-2ZNR SP 62 25x62x17
30 62 16 206 206 NR SP 62 30x62x16
62 16 206-Z 206-ZNR SP 62 30x62x16
62 16 206-2Z 206-2ZNR SP 62 30x62x16
72 19 306 306 NR SP 72 30x72x19
72 19 306-Z 306-ZNR SP 72 30x72x19
72 19 306-2Z 306-2ZNR SP 72 30x72x19
35 72 17 207 207 NR SP 72 35x72x17
72 17 207-Z 207-ZNR SP 72 35x72x17
72 17 207-2Z 207-2ZNR SP 72 35x72x17
80 21 307 307 NR SP 80 35x80x21
80 21 307-Z 307-ZNR SP 80 35x80x21
80 21 307-2Z 307-2ZNR SP 80 35x80x21
40 80 18 208 208 NR SP 80 40x80x18
80 18 208-Z 208-ZNR SP 80 40x80x18
80 18 208-2Z 208-2ZNR SP 80 40x80x18
90 23 308 308 NR SP 90 40x90x23
90 23 308-Z 308-ZNR SP 90 40x90x23
90 23 308-2Z 308-2ZNR SP 90 40x90x23
45 85 19 209 209 NR SP 85 45x85x19
85 19 209-Z 209-ZNR SP 85 45x85x19
85 19 209-2Z 209-2ZNR SP 85 45x85x19
100 25 309 309 NR SP 100 45x100x25
100 25 309-Z 309-ZNR SP 100 45x100x25
100 25 309-2Z 309-2ZNR SP 100 45x100x25
50 90 20 210 210 NR SP 90 50x90x20
90 20 210-Z 210-ZNR SP 90 50x90x20
90 20 210-2Z 210-2ZNR SP 90 50x90x20
110 27 310 310 NR SP 110 50x110x27
110 27 310-Z 310-ZNR SP 110 50x110x27
110 27 310-2Z 310-2ZNR SP 110 50x110x27
55 100 21 211 211 NR SP 100 55x100x21
100 21 211-Z 211-ZNR SP 100 55x100x21
100 21 211-2Z 211-2ZNR SP 100 55x100x21
120 29 311 311 NR SP 120 55x120x29
120 29 311-Z 311-ZNR SP 120 55x120x29
120 29 311-2Z 311-2ZNR SP 120 55x120x29
60 110 22 212 212 NR SP 110 60x110x22
110 22 212-Z 212-ZNR SP 110 60x110x22
110 22 212-2Z 212-2ZNR SP 110 60x110x22
130 31 312 312 NR SP 130 60x130x31
130 31 312-Z 312-ZNR SP 130 60x130x31
130 31 312-2Z 312-2ZNR SP 130 60x130x31
65 120 23 213 213 NR SP 120 65x120x23
120 23 213-Z 213-ZNR SP 120 65x120x23
120 23 213-2Z 213-2ZNR SP 120 65x120x23
140 33 313 313 NR SP 140 65x140x33
140 33 313-Z 313-ZNR SP 140 65x140x33
140 33 313-2Z 313-2ZNR SP 140 65x140x33
70 125 24 214 214 NR SP 125 70x125x24
125 24 214-Z 214-ZNR SP 125 70x125x24
125 24 214-2Z 214-2ZNR SP 125 70x125x24
150 35 314 314 NR SP 150 70x150x35
150 35 314-Z 314-ZNR SP 150 70x150x35
150 35 314-2Z 314-2ZNR SP 150 70x150x35
75 130 25 215 215 NR SP 130 75x130x25
130 25 215-Z 215-ZNR SP 130 75x130x25
130 25 215-2Z 215-2ZNR SP 130 75x130x25
160 37 315 – – 75x160x37
160 37 315-Z – – 75x160x37
160 37 315-2Z – – 75x160x37
80 140 26 216 216 NR SP 140 80x140x26
140 26 216-Z 216-ZNR SP 140 80x140x26
140 26 216-2Z 216-2ZNR SP 140 80x140x26
170 39 316 – – 80x170x39
170 39 316-Z – – 80x170x39
170 39 316-2Z – – 80x170x39
85 150 28 217 217 NR SP 150 85x150x28
150 28 217-Z – – 85x150x28
150 28 217-2Z – – 85x150x28
180 41 317 – – 85x180x41
180 41 317-Z – – 85x180x41
180 41 317-2Z – – 85x180x41
90 160 30 218 218 NR SP 160 90x160x30
160 30 218-Z – – 90x160x30
160 30 218-2Z – – 90x160x30
190 43 318 – – 90x190x43
190 43 318-Z – – 90x190x43
190 43 318-2Z – – 90x190x43
95 170 32 219 219 NR SP 170 95x170x32
170 32 219-Z – – 95x170x32
170 32 219-2Z – – 95x170x32
100 180 34 220 – – 100x180x34
180 34 220-Z – – 100x180x34
180 34 220-2Z – – 100x180x34

1.6 Double row deep groove ball bearings

Principal dimensions Designation
d D B
10 30 14 4200 ATN9
12 32 14 4201 ATN9
37 17 4301 ATN9
15 35 14 4202 ATN9
42 17 4302 ATN9
17 40 16 4203 ATN9
47 19 4303 ATN9
20 47 18 4204 ATN9
52 21 4304 ATN9
25 52 18 4205 ATN9
62 24 4305 ATN9
30 62 20 4206 ATN9
72 27 4306 ATN9
35 72 23 4207 ATN9
80 31 4307 ATN9
40 80 23 4208 ATN9
90 33 4308 ATN9
45 85 23 4209 ATN9
100 36 4309 ATN9
50 90 23 4210 ATN9
110 40 4310 ATN9
55 100 25 4211 ATN9
120 43 4311 ATN9
60 110 28 4212 ATN9
130 46 4312 ATN9
65 120 31 4213 ATN9
140 48 4313 ATN9
70 125 31 4214 ATN9
75 130 31 4215 ATN9
160 55 4315 ATN9
80 140 33 4216 ATN9
85 150 36 4217 ATN9
90 160 40 4218 ATN9

2.1 Insert bearings with grub screws, metric shafts

Dimensions Designation
d D B
12 40 27,4 YAR 203/12-2F 12x40x27,4
15 40 27,4 YAR 203/15-2F 15x40x27,4
17 40 22,1 YAT 203 17x40x22,1
40 27,4 YAR 203-2F 17x40x27,4
20 47 25,5 YAT 204 20x47x25,5
47 31 YAR 204-2RF/HV 20x47x31
47 31 YAR 204-2RFGR/HV 20x47x31
47 31 YARAG 204 20x47x31
47 31 YAR 204-2RF 20x47x31
47 31 YAR 204-2RF/VE495 20x47x31
47 31 YAR 204-2F 20x47x31
25 52 27,2 YAT 205 25x52x27,2
52 34,1 YAR 205-2RF/HV 25x52x34,1
52 34,1 YAR 205-2RFGR/HV 25x52x34,1
52 34,1 YARAG 205 25x52x34,1
52 34,1 YAR 205-2RF 25x52x34,1
52 34,1 YAR 205-2RF/VE495 25x52x34,1
52 34,1 YAR 205-2F 25x52x34,1
30 62 30,2 YAT 206 30x62x30,2
62 38,1 YAR 206-2RF/HV 30x62x38,1
62 38,1 YAR 206-2RFGR/HV 30x62x38,1
62 38,1 YARAG 206 30x62x38,1
62 38,1 YAR 206-2RF 30x62x38,1
62 38,1 YAR 206-2RF/VE495 30x62x38,1
62 38,1 YAR 206-2F 30x62x38,1
35 72 33 YAT 207 35x72x33
72 42,9 YAR 207-2RF/HV 35x72x42,9
72 42,9 YAR 207-2RFGR/HV 35x72x42,9
72 42,9 YARAG 207 35x72x42,9
72 42,9 YAR 207-2RF 35x72x42,9
72 42,9 YAR 207-2RF/VE495 35x72x42,9
72 42,9 YAR 207-2F 35x72x42,9
40 80 36 YAT 208 40x80x36
80 49,2 YAR 208-2RF/HV 40x80x49,2
80 49,2 YAR 208-2RFGR/HV 40x80x49,2
80 49,2 YARAG 208 40x80x49,2
80 49,2 YAR 208-2RF 40x80x49,2
80 49,2 YAR 208-2RF/VE495 40x80x49,2
80 49,2 YAR 208-2F 40x80x49,2
45 85 37 YAT 209 45x85x37
85 49,2 YARAG 209 45x85x49,2
85 49,2 YAR 209-2RF 45x85x49,2
85 49,2 YAR 209-2F 45x85x49,2
50 90 38,8 YAT 210 50x90x38,8
90 51,6 YAR 210-2RF/HV 50x90x51,6
90 51,6 YAR 210-2RFGR/HV 50x90x51,6
90 51,6 YARAG 210 50x90x51,6
90 51,6 YAR 210-2RF 50x90x51,6
90 51,6 YAR 210-2RF/VE495 50x90x51,6
90 51,6 YAR 210-2F 50x90x51,6
55 100 55,6 YAR 211-2RF 55x100x55,6
100 55,6 YAR 211-2F 55x100x55,6
60 110 65,1 YAR 212-2RF 60x110x65,1
110 65,1 YAR 212-2F 60x110x65,1
65 120 68,3 YAR 213-2RF 65x120x68,3
120 68,3 YAR 213-2F 65x120x68,3
70 125 69,9 YAR 214-2F 70x125x69,9
75 130 73,3 YAR 215-2F 75x130x73,3
80 140 77,8 YAR 216-2F 80x140x77,8
90 160 89 YAR 218-2F 90x160x89
100 180 98,4 YAR 220-2F 100x180x98,4

2.2 Insert bearings with grub screws, inch shafts

Dimensions Designation
d D B
12,7 40 27,4 YAR 203-008-2F
5/8 40 22,1 YAT 203-010
15,875 40 27,4 YAR 203-010-2F
3/4 47 25,5 YAT 204-012
19,05 47 31 YAR 204-012-2RF/HV
47 31 YAR 204-012-2RFGR/HV
47 31 YAR 204-012-2RF
47 31 YAR 204-012-2RF/VE495
47 31 YAR 204-012-2F
22,225 52 27,2 YAT 205-014
15/16 52 27,2 YAT 205-015
23,813 52 34,1 YAR 205-015-2RF/VE495
52 34,1 YAR 205-015-2F
1 52 27,2 YAT 205-100
25,4 52 34,1 YAR 205-100-2RF/HV
52 34,1 YAR 205-100-2RFGR/HV
52 34,1 YARAG 205-100
52 34,1 YAR 205-100-2RF
52 34,1 YAR 205-100-2RF/VE495
52 34,1 YAR 205-100-2F
26,988 62 38,1 YAR 206-101-2F
1,125 62 38,1 YARAG 206-102
28,575 62 38,1 YAR 206-102-2F
1,1875 62 30,2 YAT 206-103
30,163 62 38,1 YAR 206-103-2RF/HV
62 38,1 YAR 206-103-2RFGR/HV
62 38,1 YARAG 206-103
62 38,1 YAR 206-103-2RF/VE495
62 38,1 YAR 206-103-2F

2.3 Insert bearings with an eccentric locking collar, metric shafts

Dimensions Designation
d D B
15 40 19,1 YET 203/15
17 40 19,1 YET 203
20 47 21 YET 204
47 21 YET 204/VL065
47 34,2 YELAG 204
47 34,2 YEL 204-2RF/VL065
47 34,2 YEL 204-2F
25 52 21,5 YET 205
52 21,5 YET 205/VL065
52 34,9 YELAG 205
52 34,9 YEL 205-2RF/VL065
52 34,9 YEL 205-2F
30 62 23,8 YET 206
62 23,8 YET 206/VL065
62 36,5 YELAG 206
62 36,5 YEL 206-2RF/VL065
62 36,5 YEL 206-2F
35 72 25,4 YET 207
72 25,4 YET 207/VL065
72 37,6 YELAG 207
72 37,6 YEL 207-2RF/VL065
72 37,6 YEL 207-2F
40 80 29,7 YET 208
80 29,7 YET 208/VL065
80 42,8 YELAG 208
80 42,8 YEL 208-2RF/VL065
80 42,8 YEL 208-2F
45 85 30,2 YET 209
85 42,8 YELAG 209
85 42,8 YEL 209-2F
50 90 30,2 YET 210
90 49,2 YELAG 210
90 49,2 YEL 210-2F
55 100 32,6 YET 211
100 55,6 YEL 211-2F
60 110 36,7 YET 212
110 61,9 YEL 212-2F

2.4 Insert bearings with an eccentric locking collar, inch shafts

Dimensions Designation
d D B
in /mm mm –
1/2 40 19,1 YET 203-008
12,7
3/4 47 21 YET 204-012
19,05 47 34,2 YEL 204-012-2F
1 52 21,5 YET 205-100
25,4 52 34,9 YELAG 205-100
52 34,9 YEL 205-100-2F
1 1/8 62 23,8 YET 206-102
28,575 62 36,5 YELAG 206-102
62 36,5 YEL 206-102-2F
1 3/16 62 23,8 YET 206-103
30,163 62 36,5 YELAG 206-103
62 36,5 YEL 206-103-2F
1 1/4 62 23,8 YET 206-104
31,75 72 25,4 YET 207-104
72 37,6 YELAG 207-104
72 37,6 YEL 207-104-2F
1 5/16 72 25,4 YET 207-105
33,338
1 3/8 72 25,4 YET 207-106
34,925 72 37,6 YELAG 207-106
72 37,6 YEL 207-106-2F
1 7/16 72 25,4 YET 207-107
36,513 72 37,6 YELAG 207-107
72 37,6 YEL 207-107-2F
1 1/2 80 29,7 YET 208-108
38,1 80 42,8 YELAG 208-108
80 42,8 YEL 208-108-2F
1 11/16 85 30,2 YET 209-111
42,863 85 42,8 YELAG 209-111
85 42,8 YEL 209-111-2F
1 3/4 85 30,2 YET 209-112
44,45 85 42,8 YELAG 209-112
85 42,8 YEL 209-112-2F
1 15/16 90 49,2 YELAG 210-115
49,213 90 49,2 YEL 210-115-2F
2 100 55,6 YEL 211-200-2F
2 3/16 100 55,6 YEL 211-203-2F
55,563
2 7/16 110 36,7 YET 212-207
61,913 110 61,9 YEL 212-207-2F

2.5 SKF ConCentra insert bearings, metric shafts

Dimensions Designation
d D B
25 52 33,2 YSPAG 205
52 33,2 YSP 205 SB-2F
30 62 37,2 YSPAG 206
62 37,2 YSP 206 SB-2F
35 72 39,7 YSPAG 207
72 39,7 ▶ YSP 207 SB-2F
40 80 43,1 YSPAG 208
80 43,1 ▶ YSP 208 SB-2F
45 85 44,2 YSPAG 209
85 44,2 YSP 209 SB-2F
50 90 46,2 YSPAG 210
90 46,2 ▶ YSP 210 SB-2F
55 100 49,2 YSP 211 SB-2F
60 110 51,7 YSP 212 SB-2F

2.6 SKF ConCentra insert bearings, inch shafts

Dimensions Designation
d D B
1 52 33,2 YSPAG 205-100
25,4 52 33,2 YSP 205-100 SB-2F
1 3/16 62 37,2 YSPAG 206-103
30,163 62 37,2 YSP 206-103 SB-2F
1 1/4 72 39,7 YSPAG 207-104
31,75 72 39,7 YSP 207-104 SB-2F
1 3/8 72 39,7 YSPAG 207-106
34,925 72 39,7 YSP 207-106 SB-2F
1 7/16 72 39,7 YSPAG 207-107
36,513 72 39,7 YSP 207-107 SB-2F
1 1/2 80 43,1 YSPAG 208-108
38,1 80 43,1 YSP 208-108 SB-2F
1 11/16 85 44,2 YSPAG 209-111
42,863 85 44,2 YSP 209-111 SB-2F
1 15/16 90 46,2 YSPAG 210-115
49,213 90 46,2 YSP 210-115 SB-2F
2 100 49,2 YSP 211-200 SB-2F
50,8
2 3/16 100 49,2 YSP 211-203 SB-2F
55,563
2 1/4 110 51,7 YSP 212-204 SB-2F
57,15
2 7/16 110 51,7 YSP 212-207 SB-2F
61,913
2 11/16 120 52,7 YSP 213-211 SB-2F
68,263

2.7 Insert bearings with a tapered bore on an adapter sleeve, metric shafts

Dimensions Designations
d D B
20 52 24 YSA 205-2FK H 2305
25 62 28 YSA 206-2FK H 2306
30 72 30,5 YSA 207-2FK H 2307
35 80 33,9 YSA 208-2FK H 2308
40 85 35 YSA 209-2FK H 2309
45 90 37 YSA 210-2FK H 2310
50 100 40 YSA 211-2FK H 2311
55 110 42,5 YSA 212-2FK H 2312
60 120 43,5 YSA 213-2FK H 2313

2.8 Insert bearings with a tapered bore on an adapter sleeve, inch shafts

Dimensions Designations
d D B
3/4 52 24 YSA 205-2FK HE 2305
19,05
15/16 62 28 YSA 206-2FK HA 2306
23,813
1 62 28 YSA 206-2FK HE 2306
25,4
1.187 72 30,5 YSA 207-2FK HA 2307
30,136
1 1/4 80 33,9 YSA 208-2FK HE 2308
31,75
1 7/16 85 35 YSA 209-2FK HA 2309
36,513
1 1/2 85 35 YSA 209-2FK HE 2309
38,1
1 11/16 90 37 YSA 210-2FK HA 2310
42,863
1 3/4 90 37 YSA 210-2FK HE 2310
44,45
1 15/16 100 40 YSA 211-2FK HA 2311
49,213
2 100 40 YSA 211-2FK HE 2311 B
50,8
2 3/16 120 43,5 YSA 213-2FK HA 2313
55,563
2 1/4 120 43,5 YSA 213-2FK HE 2313
57,15

2.9 Insert bearings with a standard inner ring, metric shafts

Dimensions Designation
d D B
17 40 12 1726203-2RS1
20 47 14 1726204-2RS1
25 52 15 1726205-2RS1
62 17 1726305-2RS1
30 62 16 1726206-2RS1
72 19 1726306-2RS1
35 72 17 1726207-2RS1
80 21 1726307-2RS1
40 80 18 1726208-2RS1
90 23 1726308-2RS1
45 85 19 1726209 B-2RS1/VP274
85 19 1726209-2RS1
100 25 1726309-2RS1
100 25 1726309 B-2RS1/VP274
50 90 20 1726210-2RS1
110 27 1726310 B-2RS1/VP274
110 27 1726310-2RS1
55 100 21 1726211-2RS1
60 110 22 1726212-2RS1

3.1 Single row angular contact ball bearings

Principal dimensions Designations
Universally matchable bearing Basic design / sealed bearing
d D B
10 30 9 7200 BECBP 7200 BEP
12 32 10 7201 BECBP 7201 BEP
37 12 – 7301 BE-2RZP
37 12 – 7301 BEP
15 35 11 – 7202 BE-2RZP
35 11 – 7202 BEP
35 11 7202 BECBP –
35 11 7202 ACCBM –
42 13 – 7302 BE-2RZP
42 13 7302 BECBP 7302 BEP
17 40 12 – 7203 BE-2RZP
40 12 – 7203 BEP
40 12 7203 BECBP –
40 12 7203 BECBM –
40 12 – 7203 BEY
40 12 7203 ACCBM –
47 14 – 7303 BE-2RZP
47 14 7303 BECBP 7303 BEP
20 47 14 – 7204 BE-2RZP
47 14 – 7204 BEP
47 14 7204 BECBP –
47 14 7204 BECBPH –
47 14 7204 BECBY –
47 14 7204 BECBM –
47 14 7204 ACCBM –
52 15 – 7304 BE-2RZP
52 15 – 7304 BEP
52 15 7304 BECBP –
52 15 7304 BECBPH –
52 15 7304 BECBM –
52 15 7304 BECBY –
52 15 7304 ACCBM –
25 52 15 – 7205 BE-2RZP
52 15 – 7205 BEP
52 15 – 7205 BEY
52 15 7205 BECBP –
52 15 7205 BECBY –
52 15 7205 BECBM –
52 15 7205 BECBPH –
52 15 7205 ACCBM –
62 17 – 7305 BE-2RZP
62 17 – 7305 BEP
62 17 – 7305 BEY
62 17 7305 BECBP –
62 17 7305 BECBPH –
62 17 7305 BECBY –
62 17 7305 BECBM –
62 17 7305 ACCBM –
30 62 16 – 7206 BE-2RZP
62 16 – 7206 BEP
62 16 7206 BECBP –
62 16 7206 BECBPH –
62 16 7206 BECBM –
62 16 7206 BECBY –
62 16 7206 ACCBM –
72 19 – 7306 BE-2RZP
72 19 – 7306 BEP
72 19 7306 BECBP –
72 19 7306 BEGAPH –
72 19 7306 BECBM –
72 19 7306 BECBY –
72 19 7306 ACCBM –
35 72 17 – 7207 BE-2RZP
72 17 – 7207 BEP
72 17 7207 BECBP –
72 17 7207 BECBM –
72 17 7207 BECBY –
72 17 7207 ACCBM –
80 21 – 7307 BE-2RZP
80 21 – 7307 BEP
80 21 7307 BECBP –
80 21 7307 BECBY –
80 21 7307 BEGAPH –
80 21 7307 BECBM –
80 21 7307 ACCBM –
40 80 18 – 7208 BE-2RZP
80 18 – 7208 BEP
80 18 7208 BECBP –
80 18 7208 BECBPH –
80 18 7208 BECBM –
80 18 7208 BECBY –
80 18 7208 ACCBM –
90 23 – 7308 BE-2RZP
90 23 – 7308 BEP
90 23 7308 BECBP –
90 23 7308 BEGAPH –
90 23 7308 BECBM –
90 23 7308 BECBY –
90 23 7308 ACCBM –
45 85 19 – 7209 BE-2RZP
85 19 7209 BECBP –
85 19 7209 BEGAPH –
85 19 7209 BECBM –
85 19 7209 BECBY –
85 19 7209 ACCBM –
100 25 – 7309 BE-2RZP
100 25 – 7309 BEP
100 25 7309 BECBP –
100 25 7309 BEGAPH –
100 25 7309 BECBM –
100 25 7309 BECBY –
100 25 7309 ACCBM –
50 90 20 – 7210 BE-2RZP
90 20 – 7210 BEP
90 20 7210 BECBP –
90 20 7210 BECBPH –
90 20 7210 BECBM –
90 20 7210 BECBY –
90 20 7210 ACCBM –
110 27 – 7310 BE-2RZP
110 27 7310 BECBP –
110 27 7310 BEGAPH –
110 27 7310 BECBM –
110 27 7310 BECBY –
110 27 7310 ACCBM –
55 100 21 – 7211 BE-2RZP
100 21 – 7211 BEP
100 21 7211 BECBP –
100 21 7211 BECBPH –
100 21 7211 BECBM –
100 21 7211 BECBY –
100 21 7211 ACCBM –
120 29 – 7311 BEP
120 29 7311 BECBP –
120 29 7311 BECBPH –
120 29 7311 BECBM –
120 29 7311 BECBY –
120 29 7311 ACCBM –
60 110 22 – 7212 BEP
110 22 7212 BECBP –
110 22 7212 BECBPH –
110 22 7212 BECBY –
110 22 7212 BECBM –
110 22 7212 ACCBM –
130 31 – 7312 BEP
130 31 7312 BECBP –
130 31 7312 BECBPH –
130 31 7312 BECBY –
130 31 7312 BECBM –
130 31 7312 ACCBM –
65 120 23 – 7213 BEP
120 23 7213 BECBP –
120 23 7213 BECBY –
120 23 7213 BEGAPH –
120 23 7213 BECBM –
120 23 7213 ACCBM –
140 33 – 7313 BEP
140 33 7313 BECBP –
140 33 7313 BECBPH –
140 33 7313 BECBY –
140 33 7313 BECBM –
140 33 7313 ACCBM –
70 125 24 – 7214 BEP
125 24 7214 BECBP –
125 24 7214 BECBPH –
125 24 7214 BECBM –
125 24 7214 BECBY –
125 24 7214 ACCBM –
150 35 – 7314 BEP
150 35 7314 BECBP –
150 35 7314 BECBPH –
150 35 7314 BECBY –
150 35 7314 BEGAPH –
150 35 7314 BECBM –
150 35 7314 ACCBM –
75 130 25 – 7215 BEP
130 25 7215 BECBM –
130 25 7215 BECBP –
130 25 7215 BECBPH –
130 25 7215 BECBY –
160 37 – 7315 BEP
160 37 7315 BECBP –
160 37 7315 BECBY –
160 37 7315 BEGAPH –
160 37 7315 BECBM –
80 140 26 – 7216 BEP
140 26 7216 BECBP –
140 26 7216 BECBPH –
140 26 7216 BECBY –
140 26 7216 BEGAPH –
140 26 7216 BECBM –
170 39 – 7316 BEP
170 39 – 7316 BEM
170 39 7316 BECBP –
170 39 7316 BECBPH –
170 39 7316 BECBY –
170 39 7316 BECBM –
85 150 28 – 7217 BEP
150 28 7217 BECBP –
150 28 7217 BECBY –
150 28 7217 BECBM –
180 41 – 7317 BEP
180 41 – 7317 BEM
180 41 7317 BECBP –
180 41 7317 BECBY –
180 41 7317 BEGAPH –
180 41 7317 BECBM –
90 160 30 – 7218 BEP
160 30 7218 BECBP –
160 30 7218 BECBY –
160 30 7218 BECBM –
190 43 – 7318 BEP
190 43 – 7318 BEM
190 43 7318 BECBP –
190 43 7318 BECBY –
190 43 7318 BEGAPH –
190 43 7318 BECBM –
95 170 32 – 7219 BEP
170 32 7219 BECBP –
170 32 7219 BECBY –
170 32 7219 BEGAPH –
170 32 7219 BECBM –
200 45 – 7319 BEP
200 45 – 7319 BEM
200 45 7319 BECBP –
200 45 7319 BECBY –
200 45 7319 BECBM –
100 180 34 – 7220 BEP
180 34 7220 BECBP –
180 34 7220 BECBY –
180 34 7220 BECBM –
215 47 – 7320 BEM
215 47 – 7320 BEP
215 47 7320 BECBP –
215 47 7320 BECBY –
215 47 7320 BECBM –
105 190 36 7221 BECBP -
190 36 7221 BECBM -
225 49 – 7321 BEP
225 49 7321 BECBP -
225 49 7321 DECBM -
110 200 38 – 7222 BEP
200 38 7222 BECBP –
200 38 7222 BECBY –
200 38 7222 BECBM –
240 50 – 7322 BEY
240 50 – 7322 BEM
240 50 7322 BECBP –
240 50 7322 BECBY –
240 50 7322 BECBM –
120 180 28 7024 BGM –
215 40 7224 BCBM 7224 BM
260 55 7324 BCBM –
130 230 40 7226 BCBM 7226 BM
280 58 7326 BCBM 7326 BM
140 210 33 7028 BGM –
250 42 7228 BCBM 7228 BM
300 62 7328 BCBM –
150 225 35 7030 BGM –
270 45 7230 BCBM –
320 65 7330 BCBM –
160 290 48 7232 BCBM –
170 260 42 7034 BGM –
310 52 7234 BCBM –
360 72 7334 BCBM –
180 280 46 7036 BGM –
320 52 7236 BCBM –
380 75 7336 BCBM –
190 290 46 7038 BGM –
340 55 7238 BCBM –
400 78 7338 BCBM –
200 310 51 7040 BGM –
360 58 7240 BCBM –
420 80 7340 BCBM –
220 340 56 7044 BGM –
400 65 7244 BCBM –
240 360 56 7048 BGM –
440 72 7248 BCBM –
260 400 65 7052 BGM –
280 420 65 7056 BGM –
500 80 – 7256 BM
300 540 85 7260 BCBM –

3.2 Double row angular contact ball bearings

Principal dimensions Designations
d D B Metal cage Polyamide cage
10 30 14 – 3200 ATN9
12 32 15,9 – 3201 ATN9
15 35 15,9 – 3202 ATN9
42 19 – 3302 ATN9
17 40 17,5 – 3203 ATN9
47 22,2 – 3303 ATN9
20 47 20,6 3204 A 3204 ATN9
52 22,2 3304 A 3304 ATN9
25 52 20,6 3205 A 3205 ATN9
62 25,4 3305 A 3305 ATN9
30 62 23,8 3206 A 3206 ATN9
72 30,2 3306 A 3306 ATN9
35 72 27 3207 A 3207 ATN9
80 34,9 3307 A 3307 ATN9
80 34,9 3307 DJ1 –
40 80 30,2 3208 A 3208 ATN9
90 36,5 3308 DNRCBM –
90 36,5 3308 A 3308 ATN9
90 36,5 3308 DMA –
90 36,5 3308 DTN9 –
45 85 30,2 3209 A 3209 ATN9
100 39,7 3309 DNRCBM –
100 39,7 3309 A 3309 ATN9
100 39,7 3309 DMA –
50 90 30,2 3210 A 3210 ATN9
110 44,4 3310 DNRCBM –
110 44,4 3310 A 3310 ATN9
110 44,4 3310 DMA –
55 100 33,3 3211 A 3211 ATN9
120 49,2 3311 DNRCBM –
120 49,2 3311 DMA –
120 49,2 3311 A 3311 ATN9
60 110 36,5 3212 A 3212 ATN9
130 54 3312 A –
65 120 38,1 3213 A –
140 58,7 3313 DNRCBM –
140 58,7 3313 A –
70 125 39,7 3214 A –
150 63,5 3314 A –
75 130 41,3 3215 A –
160 68,3 3315 A –
80 140 44,4 3216 A –
170 68,3 3316 A –
85 150 49,2 3217 A –
180 73 3317 A –
90 160 52,4 3218 A –
190 73 3318 A –
95 170 55,6 3219 A –
200 77,8 3319 A –
100 180 60,3 3220 A –
215 82,6 3320 A –
110 200 69,8 3222 A –
240 92,1 3322 A –

3.3 Capped double row angular contact ball bearings

Principal dimensions Designations
Bearing with
d D B shields seals
10 30 14 3200 A-2Z 3200 A-2RS1
12 32 15,9 3201 A-2Z 3201 A-2RS1
15 35 15,9 3202 A-2Z 3202 A-2RS1
42 19 3302 A-2Z 3302 A-2RS1
17 40 17,5 3203 A-2Z 3203 A-2RS1
47 22,2 3303 A-2Z 3303 A-2RS1
20 47 20,6 3204 A-2Z 3204 A-2RS1
52 22,2 3304 A-2Z 3304 A-2RS1
25 52 20,6 3205 A-2Z 3205 A-2RS1
62 25,4 3305 A-2Z 3305 A-2RS1
30 62 23,8 3206 A-2Z 3206 A-2RS1
72 30,2 3306 A-2Z 3306 A-2RS1
35 72 27 3207 A-2Z 3207 A-2RS1
80 34,9 3307 A-2Z 3307 A-2RS1
40 80 30,2 3208 A-2Z 3208 A-2RS1
90 36,5 3308 A-2Z 3308 A-2RS1
45 85 30,2 3209 A-2Z 3209 A-2RS1
100 39,7 3309 A-2Z 3309 A-2RS1
50 90 30,2 3210 A-2Z 3210 A-2RS1
110 44,4 3310 A-2Z 3310 A-2RS1
55 100 33,3 3211 A-2Z 3211 A-2RS1
120 49,2 3311 A-2Z 3311 A-2RS1
60 110 36,5 3212 A-2Z 3212 A-2RS1
130 54 3312 A-2Z –
65 120 38,1 3213 A-2Z 3213 A-2RS1
140 58,7 3313 A-2Z –
70 125 39,7 3214 A-2Z –
150 63,5 3314 A-2Z –
75 130 41,3 3215 A-2Z –
160 68,3 3315 A-2Z –

3.4 Four-point contact ball bearings

Principal dimensions Designations
Bearing
d D B with locating slots without locating slots
15 35 11 QJ 202 N2MA –
17 40 12 QJ 203 N2MA –
47 14 QJ 303 N2MA –
20 52 15 QJ 304 N2MA QJ 304 MA
52 15 QJ 304 N2PHAS –
25 52 15 QJ 205 N2MA –
62 17 QJ 305 N2MA QJ 305 MA
30 62 16 QJ 206 N2MA QJ 206 MA
72 19 QJ 306 N2MA QJ 306 MA
72 19 QJ 306 N2PHAS –
35 72 17 QJ 207 N2MA –
80 21 QJ 307 N2MA QJ 307 MA
80 21 QJ 307 N2PHAS –
40 80 18 – QJ 208 MA
90 23 QJ 308 N2MA QJ 308 MA
90 23 QJ 308 N2PHAS –
45 85 19 – QJ 209 MA
100 25 QJ 309 N2MA QJ 309 MA
100 25 QJ 309 N2PHAS QJ 309 PHAS
50 90 20 – QJ 210 MA
110 27 – QJ 310 MA
110 27 – QJ 310 PHAS
55 100 21 QJ 211 N2MA QJ 211 MA
120 29 QJ 311 N2MA QJ 311 MA
60 110 22 QJ 212 N2PHAS –
110 22 QJ 212 N2MA QJ 212 MA
130 31 QJ 312 N2MA QJ 312 MA
130 31 – QJ 312 PHAS
65 120 23 QJ 213 N2PHAS –
120 23 QJ 213 N2MA QJ 213 MA
140 33 QJ 313 N2PHAS –
140 33 – QJ 313 MA
70 125 24 QJ 214 N2MA QJ 214 MA
125 24 QJ 214 N2PHAS –
150 35 QJ 314 N2MA QJ 314 MA
150 35 QJ 314 N2PHAS –
75 130 25 QJ 215 N2MA QJ 215 MA
130 25 QJ 215 N2PHAS –
160 37 QJ 315 N2MA –
160 37 QJ 315 N2PHAS –
80 140 26 QJ 216 N2MA QJ 216 MA
170 39 QJ 316 N2MA –
170 39 QJ 316 N2PHAS –
85 150 28 QJ 217 N2MA QJ 217 MA
180 41 QJ 317 N2MA –
90 160 30 QJ 218 N2MA –
190 43 QJ 318 N2MA –
190 43 QJ 318 N2PHAS –
95 170 32 QJ 219 N2MA –
200 45 QJ 319 N2MA –
200 45 QJ 319 N2PHAS –
100 180 34 QJ 220 N2MA –
215 47 QJ 320 N2MA –
110 200 38 QJ 222 N2MA –
240 50 QJ 322 N2MA –
120 215 40 QJ 224 N2MA –
260 55 QJ 324 N2MA –
130 230 40 QJ 226 N2MA –
280 58 QJ 326 N2MA –
140 250 42 QJ 228 N2MA –
300 62 QJ 328 N2MA –
150 270 45 QJ 230 N2MA –
320 65 QJ 330 N2MA –
160 290 48 QJ 232 N2MA –
340 68 QJ 332 N2MA –
170 310 52 QJ 234 N2MA –
360 72 QJ 334 N2MA –
180 320 52 QJ 236 N2MA –
380 75 QJ 336 N2MA –
190 340 55 QJ 238 N2MA –
400 78 QJ 338 N2MA –
200 360 58 QJ 240 N2MA –

4.1 Self-aligning ball bearings

Principal Designations
dimensions Bearing with
d D B cylindrical bore tapered bore
5 19 6 135 TN9 –
6 19 6 126 TN9 –
7 22 7 127 TN9 –
8 22 7 108 TN9 –
9 26 8 129 TN9 –
10 30 9 1200 ETN9 –
30 14 2200 E-2RS1TN9 –
30 14 2200 ETN9 –
12 32 10 1201 ETN9 –
32 14 2201 E-2RS1TN9 –
32 14 2201 ETN9 –
37 12 1301 ETN9 –
37 17 2301 –
15 35 11 1202 ETN9 –
35 14 2202 E-2RS1TN9 –
35 14 2202 ETN9 –
42 13 1302 ETN9 –
42 17 2302 E-2RS1TN9 –
42 17 2302 –
17 40 12 1203 ETN9 –
40 16 2203 E-2RS1TN9 –
40 16 2203 ETN9 –
47 14 1303 ETN9 –
47 19 2303 E-2RS1TN9 –
47 19 2303 M –
20 47 14 1204 ETN9 1204 EKTN9
47 18 2204 E-2RS1TN9 –
47 18 2204 ETN9 –
52 15 1304 ETN9 –
52 21 2304 E-2RS1TN9 –
52 21 2304 TN9 –
25 52 15 1205 ETN9 1205 EKTN9
52 18 2205 E-2RS1TN9 2205 E-2RS1KTN9
52 18 2205 ETN9 2205 EKTN9
62 17 1305 ETN9 1305 EKTN9
62 24 2305 E-2RS1TN9 2305 E-2RS1KTN9
62 24 2305 ETN9 2305 EKTN9
30 62 16 1206 ETN9 1206 EKTN9
62 20 2206 E-2RS1TN9 2206 E-2RS1KTN9
62 20 2206 ETN9 2206 EKTN9
72 19 1306 ETN9 1306 EKTN9
72 27 2306 E-2RS1TN9 2306 E-2RS1KTN9
72 27 2306 2306 K
35 72 17 1207 ETN9 1207 EKTN9
72 23 2207 E-2RS1TN9 2207 E-2RS1KTN9
72 23 2207 ETN9 2207 EKTN9
80 21 1307 ETN9 1307 EKTN9
80 31 2307 E-2RS1TN9 2307 E-2RS1KTN9
80 31 2307 ETN9 2307 EKTN9
40 80 18 1208 ETN9 1208 EKTN9
80 23 2208 E-2RS1TN9 2208 E-2RS1KTN9
80 23 2208 ETN9 2208 EKTN9
90 23 1308 ETN9 1308 EKTN9
90 33 2308 E-2RS1TN9 2308 E-2RS1KTN9
90 33 2308 ETN9 2308 EKTN9
45 85 19 1209 ETN9 1209 EKTN9
85 23 2209 E-2RS1TN9 2209 E-2RS1KTN9
85 23 2209 ETN9 2209 EKTN9
100 25 1309 ETN9 1309 EKTN9
100 36 2309 E-2RS1TN9 2309 E-2RS1KTN9
100 36 2309 ETN9 2309 EKTN9
50 90 20 1210 ETN9 1210 EKTN9
90 23 2210 E-2RS1TN9 2210 E-2RS1KTN9
90 23 2210 ETN9 2210 EKTN9
110 27 1310 ETN9 1310 EKTN9
110 40 2310 E-2RS1TN9 2310 E-2RS1KTN9
110 40 2310 2310 K
55 100 21 1211 ETN9 1211 EKTN9
100 25 2211 E-2RS1TN9 2211 E-2RS1KTN9
100 25 2211 ETN9 2211 EKTN9
120 29 1311 ETN9 1311 EKTN9
120 43 2311 2311 K
60 110 22 1212 ETN9 1212 EKTN9
110 28 2212 E-2RS1TN9 2212 E-2RS1KTN9
110 28 2212 ETN9 2212 EKTN9
130 31 1312 ETN9 1312 EKTN9
130 46 2312 2312 K
65 120 23 1213 ETN9 1213 EKTN9
120 31 2213 E-2RS1TN9 2213 E-2RS1KTN9
120 31 2213 ETN9 2213 EKTN9
140 33 1313 ETN9 1313 EKTN9
140 48 2313 2313 K
70 125 24 1214 ETN9 –
125 31 2214 E-2RS1TN9 –
125 31 2214 –
150 35 1314 –
150 51 2314 –
75 130 25 1215 1215 K
130 31 2215 ETN9 2215 EKTN9
160 37 1315 1315 K
160 55 2315 2315 K
80 140 26 1216 1216 K
140 33 2216 ETN9 2216 EKTN9
170 39 1316 1316 K
170 58 2316 2316 K
85 150 28 1217 1217 K
150 36 2217 2217 K
180 41 1317 1317 K
180 60 2317 –
180 60 2317 M 2317 KM
90 160 30 1218 1218 K
160 40 2218 2218 K
190 43 1318 1318 K
190 64 2318 2318 K
95 170 32 1219 1219 K
170 43 2219 2219 K
200 45 1319 1319 K
200 67 2319 M 2319 KM
100 180 34 1220 1220 K
180 46 2220 2220 K
215 47 1320 1320 K
215 73 2320 2320 K
110 200 38 1222 1222 K
200 53 2222 2222 K
240 50 1322 M 1322 KM
120 215 42 1224 M 1224 KM
130 230 46 1226 M 1226 KM
150 225 56 13030 –
180 280 74 13036 –
200 280 60 13940 –
220 300 60 13944 –
240 320 60 13948 –

4.2 Self-aligning ball bearings on an adapter sleeve

Principal dimensions Designations
Bearing1) Sleeve2)
17 47 14 1204 EKTN9 H 204
20 52 15 1205 EKTN9 H 205
52 18 2205 E-2RS1KTN9 H305E
52 18 2205 EKTN9 H 305
62 17 1305 EKTN9 H 305
62 24 2305 E-2RS1KTN9 H 2305
62 24 2305 EKTN9 H 2305
25 62 16 1206 EKTN9 H 206
62 20 2206 E-2RS1KTN9 H306E
62 20 2206 EKTN9 H 306
72 19 1306 EKTN9 H 306
72 27 2306 E-2RS1KTN9 H 2306
72 27 2306 K H 2306
30 72 17 1207 EKTN9 H 207
72 23 2207 E-2RS1KTN9 H307E
72 23 2207 EKTN9 H 307
80 21 1307 EKTN9 H 307
80 31 2307 E-2RS1KTN9 H 2307 E
80 31 2307 EKTN9 H 2307
35 80 18 1208 EKTN9 H 208
80 23 2208 E-2RS1KTN9 H308E
80 23 2208 EKTN9 H 308
90 23 1308 EKTN9 H 308
90 33 2308 EKTN9 H 2308
90 33 2308 E-2RS1KTN9 H 2308
40 85 19 1209 EKTN9 H 209
85 23 2209 E-2RS1KTN9 H309E
85 23 2209 EKTN9 H 309
100 25 1309 EKTN9 H 309
100 36 2309 EKTN9 H 2309
100 36 2309 E-2RS1KTN9 H 2309
100 200 38 ▶ 1222 K H 222
200 53 2222 K H 322
240 50 1322 KM H 322
110 215 42 1224 KM H 3024
115 230 46 1226 KM H 3026

4.3 Self-aligning ball bearings with an extended inner ring

Principal dimensions Designation
d D C
20 47 14 11204 ETN9
25 52 15 11205 ETN9
30 62 16 11206 TN9
35 72 17 11207 TN9
40 80 18 11208 TN9
45 85 19 11209 TN9
50 90 20 11210 TN9
60 110 22 11212 TN9

5.1 Single direction thrust ball bearings

Principal dimensions Designation
d D C
20 47 14 11204 ETN9
25 52 15 11205 ETN9
30 62 16 11206 TN9
35 72 17 11207 TN9
40 80 18 11208 TN9
45 85 19 11209 TN9
50 90 20 11210 TN9
60 110 22 11212 TN9

5.2 Single direction thrust ball bearings with a sphered housing washer

Principal dimensions Designations
d D H1 Bearing Seat washer
12 28 13 53201 U 201
15 32 15 53202 U 202
17 35 15 53203 U 203
20 40 17 53204 U 204
25 47 19 53205 U 205
30 52 20 53206 U 206
60 25 53306 U 306
35 62 22 53207 U 207
68 28 53307 U 307
40 68 23 53208 U 208
78 31 53308 U 308
90 42 53408 U 408
45 73 24 53209 U 209
85 33 53309 U 309
50 78 26 53210 U 210
95 37 53310 U 310
110 50 53410 U 410
55 90 30 53211 U 211
105 42 53311 U 311
120 55 53411 U 411
60 95 31 53212 U 212
110 42 53312 U 312
130 58 53412 M U 412
65 100 32 53213 U 213
115 43 53313 U 313
70 105 32 53214 U 214
125 48 53314 U 314
150 69 53414 M U 414
75 110 32 53215 U 215
135 52 53315 U 315
160 75 53415 M U 415
80 115 33 53216 U 216
140 52 53316 U 316
85 125 37 53217 U 217
150 58 53317 U 317
90 135 42 53218 U 218
155 59 53318 U 318
190 88 53418 M U 418
100 150 45 53220 U 220
170 64 53320 U 320
210 98 53420 M U 420
110 160 45 53222 U 222
190 72 53322 M U 322
120 170 46 53224 U 224
210 80 53324 M U 324
130 190 53 53226 U 226
140 200 55 53228 U 228

Professzionális szervizt keresel a kerékpárod számára?

— SZAKSZERŰ KERÉKPÁR JAVÍTÁS ÉS SZERVIZ —

Itt kezdődhet a szöveged. Kattints ide, és kezdheted is az írást. Sed ut perspiciatis unde omnis iste natus error sit voluptatem accusantium doloremque laudantium totam rem aperiam.


1. Explicabo nemo enim
2. Illo inventore veritatis
3. Ratione voluptatem sequi


4. Laudantium totam rem
5. Ratione voluptatem sequi
6. Ipsum quia dolor


7. Magnam aliquam quaerat
8. Adipisci velit sed
9. Non numquam eius

Állunk rendelkezésedre

— SÜRGŐSSÉGI ELLÁTÁS —

Itt kezdődhet a szöveged. Kattints ide, és kezdheted is az írást. Sed ut perspiciatis unde omnis iste natus error sit voluptatem accusantium doloremque laudantium totam rem aperiam eaque ipsa quae ab illo inventore veritatis et quasi architecto beatae vitae dicta sunt.
